| 2. OHMCOAT
AF 485PC Series |
| Application: |
Used for MOF resistor, wire wound resistor,
PTC/NTC thermistor and so on. |
| Coating method: |
roll coating, dipping and splashing. Same as Japan Namics
paste using method. |
| Characteristic: |
1. Burning-resisted at a degree of 94V-0; cured film keeps
excellent electric characteristics.
2. Cured film has high intensity and adhesion strength.
3. Excellent dipping characteristic, suitable for dipping
application.
4. Almost no discoloration by different stoving temperatures/storage.
5. Excellent storage stability in powder as supplled. |
| Components: |
Silicone resin, Silica powder, Pigment and Additive. |
| Package: |
20kg/carcon + one bottle of additive. |
| Standard
Color: |
grey (72/73/74), green(06/07/09), red(55), black(48), blue(92).
|
|
|
|
|
|
|
|
WWR
|
MOF
|
High Power WWR
|
PTC/NTC
|
Varistor
|
| 3. CERACOAT
800P/600P Series |
| Application:
|
Used for electronic parts such as ceramic
filter, trap, resonator, discriminator, hybrid IC, network
resistor, ceramic capacitor and etc. |
| Coating method: |
Dipping and splashing. |
| Characteristic: |
| 1. |
Low stress; cured film keeps excellent electric
characteristics. |
| 2. |
Cured film has high intensity and adhesion strengty. |
| 3. |
Very stable paste condition is maintained even
after consecutive
application. |
| 4. |
Very few sedimentation and prolonged potlife
after being pasterized. |
| 5. |
Almost no discolouration by different stoving
temperstures/storage. |
|
| Components:
|
Epoxy resin (or Epoxy/Phenolic), CaCO3/Silica
powder, Pigment and Additive. |
| Package: |
25kg/pager bag. |
| Standard
Color: |
red(54), green(10/11), blue(85), white(40), grey(68), yellow(28/29/30/31/32/33/34)
|
|
 |
 |
|
Filter
|
Resonater |
 |
 |
Cremic capacitor |
HIC
|
|
|
|
